HDS272S 70Mhz Handheld Oscilloscope with Signal Generator

HDS272S 70Mhz Handheld Oscilloscope with Signal Generator

SKU: HDS272S
£270.00Price

Specifications

「Oscilloscope」Specifications

ModelHDS242HDS272HDS242SHDS272S
Bandwidth40MHz70MHz40MHz70MHz
Channels2-CH Oscilloscope2-CH Oscilloscope+1-CH Generator
Sample Rate250MSa/s
Acquisition ModelNormal, Peak detect
Record Length8K
Display3.5-inch LCD
Waveform Refresh Rate10,000 wfrms/s
Input CouplingDC, AC, and Ground
Input Impedance1 MΩ±2%, in parallel with 16pF±10pF
Probe Attenuation Factors1X,10X,100X,1000X
Max. input Voltage400V (DC+AC, PK-PK, 1MΩ input impedance) (10:1 probe attenuation)
Bandwidth Limit (typical)20MHz
Horizontal Scale5ns/div - 500s/div, step by 1 - 2 - 5
Vertical Sensitivity10mV/div - 10V/div
Vertical Resolution8 bits
Trigger TypeEdge
Trigger ModesAuto, Normal, single
Automatic MeasurementPeriod, Frequency, Mean, PK-PK, Max, Min
Cursor MeasurementΔV, ΔT, ΔT&ΔV between cursors,auto cursor
Communication InterfaceUSB Type-C

「Multimeter」Specifications (Standard)

Max. Resolution20,000 counts
Testing ModeVoltage, Current, Resistance, Capacitance, Diode ,and Continuity test
Input Impedance10MΩ
Max Input VoltageAC 750V, DC 1000V
Max Input CurrentDC : 10A AC : 10A
Diode0 - 2V

「Waveform Generator」Specifications (Only for HDS242S & HDS272S)


Frequency Output
Sine 0.1Hz - 25MHz
Square 0.1Hz - 10MHz
Ramp0.1Hz - 1MHz
Pulse0.1Hz - 5MHz
Arbitrary0.1Hz - 5MHz
Sampling Rate125MSa/s
Channel1-CH
Amplitude Range20 mVpp - 5 Vpp
Waveform Length8K
Vertical Resolution14bits
Output Impedance50Ω



Accessories

The accessories subject to final delivery.

  • CD Rom

  • Quick Guide

  • USB Cable

  • Probe Adjust

  • Multimeter Lead

  • Soft Bag

  • Multimeter Lead (optional)

  • Bolt Driver

  • Probe

  • Power Adpter

  • BNC to Alligator Clip
